Sensor Modules
MAR-2025Round PIR Motion Sensor Module
A round low-voltage PIR module with adjustable delay for embedded motion-control applications.
- Model
- MAR-2025
- Format
- Sensor Modules
- Inquiry context
- Model attached automatically
Product overview
Selection context
MAR-2025 is designed for DC sensor output in automatic lighting and related control applications. Legacy materials disagree on delay and detection-distance values; those fields must be confirmed for the selected production configuration.
Application fit
- Automatic lighting
- Ventilation control
- Embedded sensor projects
Verified fields
Specifications
- Operating voltage5-24 V DC
- Operating temperature-20 to +50 C
- Static current< 50 uA
- Output current5 A in supplied English sheet; confirm configuration
- Detection angle120-degree cone
- Dimensions50 x 40 x 22.5 mm
- Delay and rangeAdjustable; final values require confirmation
